HXS unmixed two color injection molding machines
1. With major and minor two injection components, it can inject synchronously or alternately through controlling two screw bars by the professional computer so as to get the plastic products with beautiful color.
2. Also can manufacture the sandwich plastic products, and the cost is reduced;
3. Can be widely used with PP, PE, PS and other raw materials in two color forming.
MODEL:HXS200 |
|||||||
TECHNICAL PARAMETER TABLE |
A组/B组 |
||||||
INJECTION UNIT |
SCREW DIAMETER |
mm |
28 |
32 |
36 |
40 |
|
SCREW L/D RATIO |
L/D |
22 |
23 |
21 |
21 |
||
INJECTION CAPACITY IN THEORY |
cm3 |
80 |
132 |
167 |
207 |
||
INJECTION WEIGHT(PS) |
g |
72 |
120 |
152 |
188 |
||
oz |
2.5 |
4.2 |
5.3 |
6.6 |
|||
INJECTION PRESSURE |
MPa |
236 |
297 |
234 |
190 |
||
INJECTION RATE |
g/s |
105 |
83 |
106 |
131 |
||
PLASTICIZING CAPACITY |
g/s |
9 |
11 |
13.9 |
18.4 |
||
SCREW SPEED |
rpm |
300 |
|||||
CLAMPING UNIT |
CLAMPING FORCE |
KN |
2000 |
||||
MOVING MOULD-PLATE STROKE |
mm |
500 |
|||||
MAX. MOULD HEIGHT |
mm |
570 |
|||||
MIN. MOULD HEIGHT |
mm |
250 |
|||||
SPACE BWTWEEN TIE-BARS (W*H) |
mm |
840*520 |
|||||
HYDRAULIC EJECTOR FORCE |
KN |
33 |
|||||
HYDRAULIC EJECTOR STROKE |
mm |
110 |
|||||
EJECTOR NUMBER |
n |
3*2 |
|||||
WHEEL DIAMETER |
mm |
900 |
|||||
OTHERS |
PUMP PRESSURE |
MPa |
17.5 |
||||
MOTOR POWER |
KW |
16+16 |
|||||
HEATING CAPACITY |
KW |
7 |
10.5 |
||||
MACHINE DIMENSION (L*W*H) |
m |
5.50*1.83*2.10 |
|||||
MACHINE WEIGHT |
t |
9.5 |
|||||
OIL TANK CAPACITY |
L |
410 |
|||||
BEARING CAPACITY OF ROTARY PLATEN |
t |
1.2 |
|||||
|
