Product advantages:
1.With CANbus and EtherCAT bus communication,the computer system is fully digital controlled.
2.Thetemperature control adopts special control module.The accuracy can be achieved with 1 degree.
3.With the power monitoring function,it can monitor the current energy consumption during the production.
4.The special single cylinder strcture drastically reduces the return-oil amount during the high speed injection.At the same time,it reduces the return-oil pressure,In this way,it can increase machine injection acceleration.
5.In using the graphite steel sets as well as thin oil lubrication,the bent elbow connecting rods and guide bars have better bearing resistance and abrasive resistance.The machine has a longer service life.
6.Controlled by the proportional direction valve,the movement can accelerate quickly.During the high speed running,it can operate steadily and precisely control the mold open position.
7.The hydraulic system adopts double servo drive control.It has the advantages of high efficiency; energy saving and low noise.Meanwhile,it can realize mold-open and charge synchronization function.
TECHNICAL PARAMETER TABLE | A | B | |
Screw diameter | mm | 55 | 60 |
Screw L/D ratio | L/D | 24 | 22 |
Injection capacity in theory | cm3 | 582 | 692 |
Injection weight (Ps) | g | 529 | 630 |
Injection pressure | MPa | 171 | 144 |
Injection speed | mm/s | 480 | |
Plasticizing capacity | g/s | 80 | 97 |
Screw speed | r/min | 400 | |
Clamping force | kN | 3880 | |
Opening stroke | mm | 630 | |
Max mold height | mm | 650 | |
Min mould height | mm | 250 | |
Space between tie-bar | mm | 700x660 | |
Ejector force | kN | 125 | |
Ejector stroke | mm | 140 | |
Ejector No | n | 9 | |
Pump pressure | MPa | 19 | |
Motor power | KW | 45+45 | |
Heating power | KW | 20.3 | |
Machine dimension | m | 6.98x1.81x2.04 | |
Mchine weight | t | 14 | |
Oil tank capacity | L | 600 |
